Smart City Mission Status

List of Facilities established under Smart City Mission..

1. Electrical Comparator

Direct reading type System should be able to source, measure and calibrate the Test & Measuring Equipment’s as well as Test Tools like Handheld and Bench Meters/ DMM up to 6 ½ digits ,Analog Meters like Ammeter, Voltmeter, Watt Meter, Current clamps Meter/Tung Tester and Power Clamp Meters ,Thermocouples and RTDs Indicator and Controller, Thermometer, MultiFunction Process Calibrators, Data loggers, Strip and Chart Recorders & Plotters, Power Meters ,Power Harmonics Analyser’s ,Panel Meters, Frequency Meter/Counters, Graphical Multi meters ,Power quality Analyser’s ,Analog or Digital Handheld and Bench Oscilloscopes up to 1GHz Bandwidth, Power Supplies, SMPS, Pulse/ Function Generator both manually as well as automatically.

2. Thermal Comparator

Thermal Comparator System multifunctional, Direct reading type System is capable to Source, measure and calibrate the Temperature Sensing and Measuring Instruments / Devices like Thermocouple, RTD / PRT Thermometer , Dial Gauge Thermometer , LIG Thermometers ,RH Sensor, Relative humidity Device, Infra-Red [ IR] Thermometer and other Temperature Read out Devices etc. Manually or Automatically from the Temperature range -90C. to 1500 C

3. Pressure Calibrator

Pressure Calibration System is able to generate, measure and calibrate the Pressure Sensing and Measuring Instruments / Devices like Pressure Gauge Pressure, Transmitters, Pressure Switch, and other Pressure Measuring Instruments from the pressure range -800 m bar to 1400 bar. Pressure Therefore System capable to Calibrate and Measure the pressure from -800 m bar to 1400 bar. Pressure Calibration System is controlled by Licenced Software for quick reading.

4. Dimension Comparator

Dimension Calibrator System able to generate, measure and calibrate the Sensing and Measuring Instruments / Devices like Vernier & Digital Caliper Dial Caliper , Different Gauges , Scale and Tap etc Licenced Software is available along with the System.

5. Handheld ED-XRF Spectrometer

Handheld ED-XRF Spectrometer compatible for the Measurement of Plating Thickness for Multilayer Coating Thickness Measurement, Electroplating Bath Solution Analysis Like Gold , Silver , Copper , Nickel , Brass , Platinum Palladium etc , Trace Analysis for RoHS/ ELV Compliance, Analysis of Alloy Coatings like ZnFe,ZnNi,SnAg and NiP etc , Material Composition of Different Alloys . Powder , Liquid & Solid matrix for qualitative and quantitative multi element analysis in solids, Pressed pellet, Powder, Fuse beads and liquid sample etc System is capable to test any metallic big item , Fixed Item.

6. Liquid Chromatography Mass Spectrometry [ LC – MS / MS ]

Liquid Chromatography Mass Spectrometry [ LC – MS / MS ] capable for qualitative and quantitative analysis of Aromatic Amines , Textiles Dyes , Phthalates , Stimulants , Forensic Samples , Environmental Testing , Food Testing , Residual Pesticides as per IS :14543 or Equivalent International Test Code , Polar Pesticides and Organic Compounds as per REACH Guidelines, etc

7. Optical Emission Spectrometer [ PMT BASE ]

Optical Emission Spectrometer [ PMT BASE ] Direct reading type, suitable for high accuracy analysis of solid metal samples, alloys for multi-matrices applications. System is able to determine major [ % ] , trace [ ppm ] and Ultra Trace [ ppb] level elements in single run measurement with high sensitivity, high precision , high accuracy, reproducibility of test results from trace level to concentration level (in concentration %) in Ferrous (Fe) - Low Carbon Steel, Medium Carbon Steel, High Carbon Steel, Cast Iron, Stainless Steel, Alloy steel . Zinc ( Zn) , Copper (Cu)- Copper , Brass , Bronze . Aluminum (Al) and Tin ( Sn)
